Green Sand Wear Testing Machine 0-9999 Laps Counter Range For Qualitative Inspection

Ask Lasest Price
Brand Name :	WUWAY
Model Number :	WW-CA9001
Payment Terms :	T/T
Supply Ability :	20 + pcs + per month
Delivery Time :	15 work days

Add to Cart

Product Details
Company Profile

Green Sand Wear Testing Machine 0-9999 Laps Counter Range For Qualitative Inspection

Description:

1. Its main use is to detemine the abrasion resistance of the coating surface and green sand.

2. If the sand type and the coating have poor wear resistance, not only the boundary affects the roughness of the surface, but also defects such as sand, sand, and sand

are easily generated. Therefore, their wear resistance should be tested when formulating and formulating sand.

main specifications

Dimension 460*250*210 mm
rated power ≦100W

power source AC220V/50Hz (Customized)
specimen size 50*55mm
counter range 0-9999 laps
accuracy of the number of laps ±0.5 laps
motor speed 80RPM
Card clothing size 35*16mm
the pressure from the card clothing brush without weight: 100gf±0.5gf
with 50g weight: 200gf±0.5gf
with 100g weight: 300gf±0.5gf

dimension	460250210 mm
power source	AC220V/50Hz (Customized)
rated power	≦100W
specimen size	50*55mm
counter range	0-9999 laps
accuracy of the number of laps	±0.5 laps
motor speed	80RPM
Card clothing size	35*16mm
the pressure from the card clothing brush without weight	100gf±0.5gf
with 50g weight	200gf±0.5gf
with 100g weight	300gf±0.5gf

Instrument features

It is controlled by micro computer.

main applications

It is widely used in foundry, machinery, casting, qualitative inspection, scientific research, university lab....
